SIIG SC-SAER12-S2 SATA II PCIe Raid Controller Card 2 Port 300Mbps


$55.00

UPC: 662774025650 Category:

Description

SIIG SC-SAER12-S2 SATA II PCIe Raid Controller Card 2 Port 300Mbps

A brand-new, unused, unopened, undamaged item in its original packaging.

Features
-Supports a 1-lane (x1) 2.5Gbps PCI Express bus one way
– Installs in any available PCI Express slot
– Standard height and low profile brackets are included to work in different chassis form factors
– Two internal Serial ATA generation II ports with transfer rates up to 3.0Gbps (300MBps)
– Supports RAID 0 (striping) & RAID 1 (mirroring) for speed and data protection respectively

Specifications
– Chipset: Silicon Image 3132
– Bus type: PCI Express x1
– Port type: Two internal SATA II ports
– Compliant with PCI Express Base Specification Revision 1.0a
– Compliant with Serial ATA 1.0a specification with support for full complement of SATA II optional features
– PCI Express 1-lane (x1) SATA II adapter works with PCI Express slots with different lane width
– Installs in any available PCI Express slot and supports data transfer rates up to 3.0Gbps (300MBps)
– Integrated Serial ATA Link and PHY logic
– Supports Native Command Queuing (NCQ), Non-zero offsets NCQ, and Out-of-order data delivery NCQ
– Independent command fetch, scatter/gather, and command execution
– Friendly SATARaid RAID management software utility is provided to make configuring RAID easy
– Supports 48-bit LBA and verified to work with up to 4TB drives
– Certifications/Standards: FCC, CE, RoHS
– Country of origin: China
